Application area of KSVPtpe HL-5e:
High-frequency twisted-pair cables for structured cabling systems are designed for fixed horizontal and vertical installation inside buildings and structures, as well as for stationary horizontal and vertical outdoor installation along building walls and suspension on overhead communication lines. The cables operate within a frequency range of up to 100 MHz (Category 5 and 5e according to GOST R 54429-2011) and ISO/IEC 11801 standards. The cables are manufactured in climatic version U, installation categories 1, 2, 3, and 4 in accordance with GOST 15150.
Technical specification:
|
Name |
Number of pairs and conductor diameter, mm |
Conductor diameter |
Nominal outer cable diameter with conductor diameter 0.50 mm, mm |
Cable weight with conductor diameter 0.50 mm, kg/km |
Manufacturing length, km |
|
KSVPtpe HL-5e |
1x2 |
0.46±0.01 0.48±0.01 0.50±0.01 0.51±0.01 0.52±0.01 |
3.1 |
9.05 |
0.305; 0.5; 1 |
|
2x2 |
5.2 |
18.53 |
0.305; 0.5 |
||
|
4x2 |
5.98 |
29.44 |
0.305 |
||
|
8x2 |
8.08 |
51.41 |
0.305 |
||
|
10x2 |
9.2 |
62.39 |
0.305 |
||
|
16x2 |
11.16 |
105.06 |
0.305 |
||
|
25x2 |
15.12 |
158.93 |
0.305 |
||
|
50x2 |
19.76 |
290.79 |
0.305 |
||
|
100x2 |
25.3 |
571.25 |
0.305 |
Electrical characteristics:
- Conductor resistance recalculated for 100 m cable length at 20 °C: no more than 9.5 Ohms;
- DC resistance unbalance of conductors within a working pair over 100 m length: no more than 2%.
- Attenuation coefficient recalculated for 100 m length at 20 °C, dB, not more than:
|
Frequency, MHz |
1 |
4 |
10 |
16 |
20 |
31.25 |
62.5 |
100 |
|
Attenuation, dB |
2.1 |
4.1 |
6.5 |
8.3 |
9.3 |
11.7 |
17.0 |
22.0 |
- Near-end crosstalk attenuation (NEXT) for any pair combination, recalculated for 100 m length, dB, not less than:
|
Frequency, MHz |
1 |
4 |
10 |
16 |
20 |
31.25 |
62.5 |
100 |
|
Attenuation, dB |
65.3 |
56.3 |
50.3 |
47.3 |
45.8 |
42.9 |
38.4 |
35.3 |
- Equal Level Far-End Crosstalk (ELFEXT) for any pair combination, recalculated for 100 m length, dB, not less than:
|
Frequency, MHz |
1 |
4 |
10 |
16 |
20 |
31.25 |
62.5 |
100 |
|
Attenuation, dB |
64.0 |
52.0 |
44.0 |
39.9 |
38.0 |
34.1 |
28.0 |
24.0 |
- Characteristic impedance Zc, Ohm: 100±15
Operating and installation conditions:
Cables may be operated at ambient temperatures from -60°C to +60°C. Cable installation is permitted at temperatures not lower than -40°C.
The minimum permissible bending radius during installation and laying shall be at least 8 times the maximum outer diameter of the cable.
Reliability requirements:
The minimum service life of the cables, provided that the consumer complies with the established installation rules and operating, storage, and transportation conditions, shall be at least 25 years. The service life is calculated from the date of cable manufacture.
